- Bearing Type: Ball Bearing
- Cooling System: Oil & Water Cooled
-
Turbine Housing: Externally Wastegated 0.73a/r or 0.64a/r
- Base Flange: T3 Single Entry
- Exhaust Outlet Flange: V-Band
- Horsepower: 200 - 475hp
- Displacement: 1.4L - 2.5L
Features
- GEN 2 Aerodynamics feature increased horsepower range
- New fully-machined Speed Sensor port
- Improved ported shroud design for surge resistance
- Sold as complete assembly kits (Supercore + Turbine Kit)
- Interchangeable with GT and GTX GEN I Models
Product Notes:
- Supplied with turbine outlet v-band flange, v-band Clamp, and turbine inlet gasket.
| Supercore Reference Data | Compressor | Turbine | ||||||
|---|---|---|---|---|---|---|---|---|
| Supercore P/N | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | |
| 849894-5001S | 46mm | 60mm | 58 | 0.60 | 54mm | 47mm | 76 | |
| Turbocharger P/N | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | A/R |
| 856800-5001T373 | 46mm | 60mm | 58 | 0.60 | 54mm | 47mm | 76 | 0.73 & 0.64 |
