- Bearing System: Ball Bearing
- Cooling System: Oil & Water Cooled
- Horsepower: 425 - 750
- Ported Shroud Design for Surge Resistance
- Available in both Journal Bearing and Ball Bearing options
- Forged Fully Machined Billet Compressor Wheel
- Lightweight Aluminium Backplate
- Inconel Super-Alloy Turbine Wheel
| Super Core Reference Data | Compressor | Turbine | ||||||
|---|---|---|---|---|---|---|---|---|
| Super Core PN | CHRA PN | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim |
| 841297-5002S | 715582-0007 | 62mm | 84mm | 54 | 0.70 | 71mm | 62mm | 76 |
| 841691-5002S | 757197-0011 | 62mm | 84mm | 54 | 0.70 | 71 | 62mm | 76 |
| Notes: | Turbine Kit PN | A/R | Inlet | Outlet | Wastegate | Divided | Trim | |
| Super Core and Turbine Kit Sold Separately | 844669-0005 | 0.70 | T4 | V-Band | Free Float | Y | 76 | |
| 844669-0006 | 1.00 | T4 | V-Band | Free Float | Y | 76 | ||
| 844669-0007 | 1.15 | T4 | V-Band | Free Float | Y | 76 | ||
